STS3215 30kg 12V High-Torque Servo

High-voltage variant delivering 30kg.cm torque at 12V in the same compact STS3215 form factor. Designed for applications requiring maximum force.

Specifications

• Manufacturer: FEETECH
• Model: STS3215
• SKU: ST-3215-C018
• Stall Torque: 30kg.cm (417.35oz.in) @ 12V
• Speed: 0.222sec/60° @ 12V
• Dimensions: 45.22mm × 24.7mm × 35mm
• Weight: ~55g
• Voltage Range: 7.4V - 12.6V (Rated 12V)
• Communication: TTL Serial Bus (Digital Packet)
• Encoder: 12-bit Magnetic (4096 resolution)
• Shaft: Dual-shaft
• ID Range: 1-253
• Baud Rate: 115200 (default)
• Feedback: Position, Speed, Load, Voltage, Temperature
• Protection: Overload, Overcurrent, Overvoltage, Overheat

Applications

• Heavy-duty robotic arms
• FRC/FTC competition robots
• Industrial automation prototypes
• High-load positioning systems
