Eaton FD3015L – Series C 3-Pole 15A Circuit Breaker
Details
The Eaton FD3015L is a Series C molded case circuit breaker designed for industrial and commercial applications. It features a fixed thermal and magnetic trip unit, 3 poles, and line/load terminals. Rated for 600 Vac and 250 Vdc, it offers high interrupt ratings of 65 kAIC at 240 Vac and 35 kAIC at 480 Vac. UL Listed and suitable for 50/60 Hz frequency applications.
Key Specifications
- Manufacturer: Eaton
- Series: Series C
- Part Number: FD3015L
- Frame: F
- Trip Type: Fixed Thermal, Fixed Magnetic
- Amperage Rating: 15 A
- Voltage Rating: 600 Vac, 250 Vdc
- Poles: 3
- Terminals: Line and Load
- Frequency: 50/60 Hz
- Interrupt Rating: 65 kAIC at 240 Vac, 35 kAIC at 480 Vac
- Dimensions: 3.38" L × 4.13" W × 6" H
- Certifications: UL Listed
