Eaton EHD3090 – Series C Circuit Breaker, 3-Pole, 90A, 240/480V
Details
The Eaton EHD3090 is a Series C molded case circuit breaker designed for industrial environments. It features a fixed thermal and magnetic trip unit, 3-pole configuration, and load side terminals. With interrupt ratings of 18 kAIC at 240 Vac and 14 kAIC at 480 Vac, this breaker is UL Listed and supports 50/60 Hz frequency systems.
Key Specifications
- Manufacturer: Eaton
- Series: Series C
- Part Number: EHD3090
- Frame: F
- Trip Type: Fixed Thermal, Fixed Magnetic
- Amperage Rating: 90 A
- Poles: 3
- Terminals: Load side
- Frequency: 50/60 Hz
- Interrupt Rating: 18 kAIC at 240 Vac, 14 kAIC at 480 Vac
- Dimensions: 3.38" L × 4.13" W × 6" H
- Certifications: UL Listed
