Eaton BAB3070H – 70A Quicklag Circuit Breaker, 3-Pole, 240V, Bolt-On
Details
The Eaton BAB3070H is a 70A Quicklag industrial circuit breaker designed for use in distribution panels with 240V three-phase, four-wire systems. It features a thermal-magnetic trip unit, bolt-on mounting, and an interchangeable trip mechanism. With a 10 kAIC interrupt rating and 240V voltage rating, this 3-pole breaker is UL Listed and CSA Certified for reliable protection in demanding environments.
Key Specifications
- Manufacturer: Eaton
- Part Number: BAB3070H
- Type: Quicklag Industrial Thermal-Magnetic Circuit Breaker
- Amperage Rating: 70 A
- Interrupt Rating: 10 kAIC
- Voltage Rating: 240 V
- Trip Type: Interchangeable
- Mounting Method: Bolt-on
- Number of Poles: 3
- Number of Wires: 4
- Used With: Distribution panels (240V, three-phase, four-wire)
- Special Features: HACR rated
- Dimensions: 3.9" L × 3.2" W × 4.9" H
- Certifications: UL Listed, CSA Certified
